Sensor
640×480 pix. @ 17 µm (thermal) | CMOS 1920×1200 (digital) pix. @ 17 µm (NETD < 25 mK)
Objective lens
F50/1.0 (thermal) | F50/1.4 (digital)
Magnification, x
3 – 24 (thermal) | 2 – 16 (digital)
FOV (HxV)degrees / m@100m
12.4° / 21.8 m (thermal channel) | 17.5°/30.7 m (digital channel)
Detection range
1800 (thermal detection)
Emitter
LED
Beam divergence, degree
≥ FOV
IR wavelength, nm
940
IR Optical power, mW
500
IR spot position adjustment
yes
Type
Uncooled, microbolometric (thermal) | Full-HD CMOS (digital)
Resolution, pixels
640×480 pix. @ 17 µm (thermal) | CMOS 1920×1200 (digital)
Pixel pitch, µm
17
NETD, mK
< 25
Frame rate, Hz
50

Objective lens
F50/1.0 (thermal) | F50/1.4 (digital)
Magnification, x
3 – 24 (thermal) | 2 – 16 (digital)
FOV (HxV)degrees / m@100m
12.4° / 21.8 m (thermal channel) | 17.5°/30.7 m (digital channel)
Eye relief, mm
12

Type
AMOLED HD
Resolution, pixels
1280х960

Video / photo resultion, pixel
1280х960
Video / photo format
.mp4 / .jpg
Build-in memory, GB
64
WI-FI
Wireless protocol

Wireless standard
IEEE 802.11 b/g/n/ac (WPA)
Frequency, Ghz
2.4 / 5

Degree of protectionIP code (IEC60529)
IPX7 (waterproof)
Operating temperature range, °С
-25 – +50

Body material
Magnesium alloy
Dimensions, mm
207x140x73
Weight, kg
1.2 (batteries included)
